10
wheel collar.
wheel.
Axle.
Washer.
M3.
M3.
C/A glue.
Landing Gear.
wheel Pant.
Axle.
Locker glue.
wheel Pant.
wheel.
M3.
M3.
wheel collar.
nut.
Washer.
WHEELS AND WHEEL PANTS.
1) Assemble and mounting the landing gear,
wheels to the wheel pants as shown inthe fol-
lowing pictures.
2) Follow diagram below for wheel pant in-
stallation:
3) A drop of C/A glue on the wheel collar
screws will help keep them from coming lose
during operation.
Repeat the process for the other wheel.
