17
Battery.
INSTALLING THE SPINNER.
Install the spinner backplate, propeller and
spinner cone.
e propeller should not touch any part
of the spinner cone. If it does, use a sharp
modeling knife and carefully trim away the
spinner cone where the propeller comes in
contact with it.
5) Attach the speed control to the side
of the motor box using two-sided tape
and tie wraps. Connect the appropriate
leads from the speed control to the mo-
tor. Make sure the leads will not interfere
with the operation of the motor.
Speed control.
INSTALLING THE AILERON - FLAP
SERVOS.
Servos.
Small weight.
Thread.
Because the size of servos dier, you may
need to adjust the size of the precut opening in
the mount. e notch in the sides of the mount
allow the servo lead to pass through.
1) Using a small weight (Weighted fuel pick-
up works well) and string, feed the string
through the wing as indicated.
