23
M2 lock nut.
M2 clevis.
810mm.
.
Elevator pushrod.
Elevator pushrod.
M2 lock nut.
M2 clevis.
810mm.
820 mm
RUDDER PUSHROD HORN
INSTALLATION.
Rudder control horn
M2 lock nut.
M2 clevis.
810mm.
M2 lock nut.
M2 clevis.
.
840 mm
810 mm
Rudder pushrod.
INSTALLATION PILOT AND CANOPY.
1) Locate items necessary to install pilot and
canopy.
2) A scale pilot is included with this ARF.
e Seagull Pilot included tting well
to the cockpit. (or you can order others
scale pilot gures made by Seagull fac-
tory. ey are available at Seagull factory.
ey are available at Seagull distributors.)
If you are going to install a pilot gure,
please use a sanding bar to sand the base of
the gure so that it is at.
3) Position the pilot gure on the canopy
oor as show. Locate the oval shaped on the
canopy oor and remove the covering. Use
epoxy to glue this into the base of the pilot
gure and glue the cockpit panel in place
with C/A glue, please see pictures as shown.
