INSTALLATION
MANUAL
Product:
Document #:
Rev:
Page:
SEAKEEPER 9 / 7HD
90222
9
1 of 11
Section 2: ELECTRICAL INSTALLATION
2.0 Introduction
This section for electrical installation explains how to mount the electrical equipment and how to
connect the electrical cables.
Reference Documents & Drawings
90221 Seakeeper 9 Hardware Scope of
90257
Seakeeper 9/7HD Cable Block
Supply
Diagram (includes 2nd Display Kit)
90415 Seakeeper 7HD Hardware Scope of
90438
Touchscreen Display Envelope
Supply
and Mounting Details
90223 Seakeeper 9/7HD Operation Manual
90467 2
nd
Helm Control Station Kit
SEAKEEPER 9, Front Oblique View SEAKEEPER 9, Rear Oblique View
24VDC Power Input Cable Terminator, Female Tee Adapter
Color Display USB Extension Cable 2ft Cable 25m Cable
FIGURE 1 – ELECTRICAL EQUIPMENT FOR SEAKEEPER 9
