Page 13
Original Language Version
VS8220 Issue: 2(SP) - 23/09/13
4.5.5. Zooming. Simply press UP and DOWN arrow buttons while in the still camera
mode to zoom in or out. A zoom indicator bar will be displayed on the screen as
you adjust zoom (g.12).
4.5.6. Entering the Primary Settings Screen. Pressing Setting button while in the
live screen will take you to the primary settings screen (g.13). Pressing
BACK button at any point will take you back to the live screen.
g.11
g.12
g.13
© Jack Sealey Limited 2012
