19
Installation Instructions and Owner's Manual
4.2 Installation Overview
ProTap controller should be mounted in a cool dry area.
Ensure that all wire leads are secured after connecting
them to the controller. Use four 1/4 inch corrosion proof
screws for mounting.
All electrical connections and harness must comply
with ABYC wiring standards, be rated for 105°C
(221°F), and compliant with SAE-J1128.
WARNING
Mount parallel to
boat deck
Mount vertical (parallel) to hull or wall, plus or minus 15°
15°
Expose to vibration, shocks
or excessive heat
Protect from sun
and elements
Figure 4-10.
