Installation Instructions and Owner's Manual
6.0 OPERATING MODES
ProTap controller is available in two operating modes,
B-Mode and F-Mode. These modes are designed for
different boating environments. Please see below for a
detailed description of each mode and how to utilize
the controller.
6.1 Bass/Bay B-Mode (Part # JC4010)
Jackplate Control
Trim Control
Trim control only available for
single engine applications.
NOTICE
This mode is designed to get you quickly up to speed
by memorizing the Jackplate and, if connected, trim
position. It also allows you to fine tune both Jackplate
and trim in a controlled manner by tapping the
Jackplate or trim toggle switches.
• Memorize two of your favorite Jackplate positions by
holding a Jackplate toggle switch up or down for more
than 5 seconds.
• Recall the two memorized position by holding the
Jackplate toggle switch up or down for 1-5 seconds.
• Tap the Jackplate toggle switch up or down to move
the plate in controlled 1/4“ increments.
• Multiple taps on the Jackplate toggle switch are
memorized and plate will move the same number of
increments without pausing.
• ProTap controller can control up to 2 Jackplates while
making sure they are in sync with each other.
Tilt protection not engaged when ProTap turned off.
Tilt protection not engaged if there is a loss of trim signal.
When tilting the engine, always visually check that Jack-
plate is up to prevent any steering or engine damage.
To enable, connect trim sender either direct or using a
NMEA 2000 harness as per Table 4-2:
• Memorize two of your favorite trim positions by
holding the trim toggle switch up or down for more
than 5 seconds.
• Recall the two memorized trim position by holding the
trim toggle switch up or down for 1-5 seconds.
• Tap the trim toggle switch up or down to move the
trim in set increments of 1/20 of trim range.
• Multiple taps on the trim toggle switch are memorized
and engine trim will move the same number of
increments without pausing.
WARNING
Trim control available in trim
range only. If engine in tilt
range the switch will revert
to normal operation. Move
engine back to trim range
for Trim Control.
NOTICE
