SeaStar ProTap Controller
This mode is designed to get the plate quickly up or
down when running through a really shallow water.
• Double tap Jackplate toggle switch up to move the
plate all the way up.
• Double tap Jackplate toggle switch down to move the
plate all the way down.
• Single tap on the Jackplate toggle switch up or down
will move the plate in 2” increments from your current
position.
• Continuously holding the Jackplate toggle switch up
or down will move the plate up or down during the
duration the switch is engaged.
• ProTap controller can control up to 2 Jackplates while
making sure they are in synch with each other.
To enable, connect trim sender either direct or using a
NMEA 2000 harness as per Table 4-2:
• Memorize two of your favorite trim positions by
holding the trim toggle switch up or down for more
than 5 seconds.
• Recall the two memorized trim position by holding the
trim toggle switch up or down for 1-5 seconds.
• Tap the trim toggle switch up or down to move the
trim in set increments of 1/10 of trim range.
• Multiple taps on the trim toggle switch are
memorized and engine trim will move the same
number of increments without pausing.
Connecting a trim sender signal direct via a harness or
over NMEA 2000 network to the controller will allow you
to set engine tilt protection during the initial calibration.
It allows you to set the safe position and trim/tilt
threshold. When engine moves to tilt range the
Jackplate will move up to a Safe position.
6.2 Flats F-Mode (Part # JC4020)
Tilt Protection
Tilt Protection
Jackplate Control
Connecting a trim sender signal direct via a harness or
over NMEA 2000 network to the controller will allow you
to set engine tilt protection during the initial calibration.
It allows you to set the safe position and trim/tilt
threshold. When engine moves to tilt range the
Jackplate will move up to a Safe position.
Trim Control
Trim control only available for
single engine applications.
NOTICE
Dual engine tilt protection
only available through
a NMEA 2000 harness
connection.
NOTICE
Dual engine tilt protection
only available through
a NMEA 2000 harness
connection.
NOTICE
Trim control available in trim
range only. If engine in tilt
range the switch will revert
to normal operation. Move
engine back to trim range
for Trim Control.
NOTICE
