Installation Instructions and Owner's Manual
LED Codes
Buzzer Codes
PROTAP STATUS COLOUR BLINK
PERIOD
DESCRIPTION
ProTap Controller Error Red 500ms On
500ms Off
A non-SmartStick or trim sender fault is present that
is preventing the ProTap from performing at 100%.
SmartStick Error Red Solid Colour Fault 0x7FDA[x] is active.
Trim Sender Error Red 1000ms On
1000ms Off
Fault 0x7FDB[x] is active.
Calibration Hardstop
Achieved
Purple 1000ms On
1000ms Off
Jackplate or Trim Hardstop achieved during calibration
mode. This blink sequence will be synchronized with
the buzzer for a calibration hardstop.
Calibration State Active Red/Blue 1000ms Red
1000ms Blue
ProTap is in a calibration state.
SCENARIO NO. OF
PULSES
PERIOD OF
PULSE
DESCRIPTION
Danger Fault Active Indefinite 1000ms On
1000ms Off
Provide feedback to the user of an active danger fault.
Memory Save
Command Invoked
1 pulse 500ms On
500ms Off
Provide feedback to the user that a memory save
command has been invoked (Jackplate or Trim).
Jackplate Calibration
Hardstop Achieved
1 pulse 1000ms On
1000ms Off
Provide feedback to the user that a Jackplate hardstop
has been achieved. This buzzer sequence will be
synchronized with the LED for a calibration hardstop.
Trim Calibration
Hardstop Achieved
2 pulses 1000ms On
1000ms Off
Provide feedback to the user that a Jackplate hardstop
has been achieved. This buzzer sequence will be
synchronized with the LED for a calibration hardstop.
Table 7-1. LED Codes.
Table 7-2. Buzzer Codes.
NOTICE
If error is reported the controller will switch to Normal
mode. Only one error is reported. To clear the error turn
the controller off then on. If the error is not cleared
please contact SeaStar Solutions Technical Support.
7.0 TROUBLESHOOTING
