272 If and when
Position of the bulbs
Pos.
⇒ fig. 209
Bulb function
A Brake light and side light P21W LL
B Side lights P21W LL
C Turn signal PY21W
Changing bulbs. LED lamps
All bulbs can be changed easily in the bulb holder.
Fig. 210 Position of the
bulb on the bulb holder.
Example: Left tail light in
side panel
The bulb is secured with a bayonet fastener. The table below gives
an overview of the bulb positions.
– Lightly press the defective bulb into the bulb holder, then turn it
to the left and remove it.
– Fit the new bulb, pressing it into the bulb holder and turn it to
the right as far as it will go.
– Use a cloth to remove any fingerprints from the glass part of the
bulb.
– Check whether the new bulb is working.
– Re-install the bulb holder ⇒ page 272.
Position of the bulbs
Pos.
⇒ fig. 210
Bulb function
A Turn signal PY21W
Note
● It is only possible to change the turn signal light.
● If the brake light and/or side lights with LEDs have to be replaced, the
tail light must be replaced.
Fitting the bulb holder
The bulb holder is easy to fit.
– Position the bulb holder on the tail light and align it so that it is
securely seated.
– Press the bulb holder into the tail light until it engages.
– Re-install the tail light unit ⇒ page 273.
