Model 644 23
GB
– Use an Allan bolt to attach the triangular
reinforcement to the scale platform.
– Use the sheet metal bolt to attach the
two side sections to the central column.
Step 3: Assemble the railing
You will need the following bolts:
– Position the railing on the three col-
umns. The large bore holes must point
downwards, and must be inserted into
the heads of the columns.
– Use an oval head bolt to attach the rail-
ing to the two outer columns.
1 x Allan bolts M6 2 x Oval head bolt M6
