Secure PT3 Series User Manual

Page 11 of 40
BGX701-014-R03, User Manual for PT3 Transducers
Public
(Applicable for accuracy class 1.0 and 0.5)
0-1 mA and 0-2 mA
(Applicable for accuracy class 1.0)
V
type
-5 to +5 V and -10 to +10 V
(Applicable for accuracy class 1.0, 0.5 and 0.2)
AC current
Input (I
n
) current
1 to 5 A
Measuring current range
0 to 150% I
n
Scale factor
0.6 to 1.5 of I
n
Frequency
50/60 Hz (±5%)
Output curve
mA type
20 mA, 4-20 mA and 10 mA
(Applicable for accuracy class 1.0,
0.5 and 0.2)
0-5 mA
(Applicable for accuracy class 1.0
and 0.5)
0-1 mA and 0-2 mA
(Applicable for accuracy class 1.0)
V type
-5 to +5 V and -10 to +10 V
(Applicable for accuracy class 1.0,
0.5 and 0.2)
Maximum overload current
2 x I
n
continuously
20 x In for 1 second, with up to 5 repetitions at 5 minute
intervals
Active
power/reactive
power
Input voltage (U
n
)
100 V to 500 V
(L-L)
500 V is maximum limit.
Input voltage range 0 to 130 % U
n
Input current (I
n
)
1 to 5 A
Input current range 0 to 150% I
n
Frequency 50/60 Hz (±5%)
Output curve
mA type
-20 to +20 mA, 4-20mA and -10 to
+10 mA
(Applicable for accuracy class 1.0,
0.5 and 0.2)
-5 to +5 mA
(Applicable for accuracy class 1.0
and 0.5)
