Measurement range 45 Hz to 55 Hz (on 50 Hz), or 55 Hz to 65 Hz (on 60 Hz)
Output curve mA type -20 to +20 mA, 4-20mA and
-10 to +10 mA
(Applicable for accuracy
class 1.0, 0.5 and 0.2)
-5 to +5 mA
(Applicable for accuracy
class 1.0 and 0.5)
-1 to +1 mA and -2 to +2
mA,
(Applicable for accuracy
class 1.0)
V type -5 to +5 V and -10 to +10 V
(Applicable for accuracy
class 1.0, 0.5 and 0.2)
MFT
Ranges applicable for configured input function (AC voltage, AC current, reactive
power, active power, active power factor, apparent power, load power factor, and
frequency ) as per measurement inputs shown above.
Auxiliary supply
High-auxiliary
Voltage range 80 V to 276 V AC/DC
Frequency 50/60 Hz
Maximum burden
≤11 VA, 6 W with two outputs at 750
Ω each at 20 mA
≤12 VA, 7 W with four outputs at 750
Ω each at 20 mA
Low-auxiliary
Voltage range
24 V to 80 V DC
Maximum burden
≤6 W with two outputs at 750 Ω each
at 20 mA
≤8 W with four outputs at 750 Ω
each at 20 mA
Standards compliance
Standards complied
IEC 60688 (Edition 3.0) : 2012, IEC 61010-1 (Edition 3.0) : 2010, IEC
61010-2-030 (Edition 1.0) : 2010, IEC61326-1(Edition-2) : 2012, IEC or
EN60068-2-1/-2/-3/-6/-27
Analogue outputs
Type
Current or Voltage (configurable)
Maximum load impedance ≤750 Ω for 20 mA, ≥2 kΩ for 10 V (for each output)
