Security Tronix ST-HDoC User Manual

ST-HDoC / ST-HDoC-MM
11
25
Analog / HD TVI/CVI/AHD signal input (BNC interface)
26
Video output (BNC output interface): CVBS output
27
Optical power meter interface (Optional) */ Visual fault locator interface (Optional) *
28
TDR cable open circuit and short circuit test (Optional) *
29
12V DC 1A output
30
SDI test port (BNC interface) ( Optional) *
31
LED lamp
32
RS485Interface: RS485 communication for PTZ
33
Network cable /Telephone cable test port
34
Device charging port (Mini USB)
35
No function
36
No function
37
Audio input: for testing audio pickup equipment
38
Reset the device to factory original settings

Security Tronix ST-HDoC Specifications

General

Brand	Security Tronix
Model	ST-HDoC
Category	Measuring Instruments
Language	English
