ST-HDoC / ST-HDoC-MM
2
The tester is a great compact tool for performing routine maintenance as well as new HD installations.
Test LAN cables for proper connection termination. Other functions include, LED Flashlight, 12VDC
2A power output and much more. Its portability, user-friendly design and many other functions make
the ST-HDoC an essential tool for all installers or technicians.
2.2 Features
Easy to operate 3.5” 480X320 TFT-LCD.
LED Flashlight.
User-defined shortcut keys（F1 and F2）
LCD screen with adjustable brightness/contrast/color saturation.
Automatically adapting NTSC/PAL input.
Enhanced color bar generator, new added gray-scale image test. PAL/NTSC multi-system
color bar video generator (Eight-system switchable, transmit/receive eight-system color
bar).
HD CVI camera image display, coaxial PTZ control and call up the camera OSD menu.
HD TVI camera image display, coaxial PTZ control and call up the camera OSD menu.
AHD camera image display, coaxial PTZ control and call up the camera OSD menu.
TDR cable test, test cable’s open circuit (breakpoint) and short circuit location.
PTZ address scanning for locating PTZ camera Address, Baud and Protocol.
Network cable tester: Tests LAN cable sequence of wires.
Support RS485, Baud Rate adjustable from 600 ～ 115200bps.
Supports more than thirty PTZ protocols, Such as PELCO-P, PELCO-D, SAMSUNG.
PTZ protocol analysis: Control commands are displayed to check RS485 Transmission.
