ST-HDoC / ST-HDoC-MM
22
3.3.9 SDI camera test (ST-HDoC-MM)
Connect an SDI camera to the ST-HDoC’s “SDI” interface.
Press the key to enter the tester’s main menu, then press the key to select
“SDI” , Press key to enter SDI test.
PTZ control instructions, please refer to 3.3.1 PTZ controller
3.3.10 Cable Tracer
The ST-HDoC/ ST-HDoC-MM is not equipped with the Cable Tester Function.
3.3.11 Cable tester
Press the key to enter the tester’s main menu, then press the key to select
then press to enter.
Testing a LAN or telephone cable.
Connect a LAN or telephone cable to the ST-HDoC tester, and the other end into the cable tester
marked ( No.255) . Once connected, the cable type and sequence of wires will be displayed, including
the model number of the Cable tester kit.
