Security Tronix ST-HDoC User Manual

ST-HDoC / ST-HDoC-MM
24
AC/DC
Voltage and current measurement display
Auto- range
Automatically adjust the display range based off the device tested
Data hold
When pressed, the current measurement display will hold for reference
Relative
measurement
Display the relative measurement value, press the key again to change the
display state
10A socket
For use when measuring current up to 10Amps
Over range
The current measurement is over the rated value, switch to auto-range to
obtain the proper measurement.
3) OPERATING INSTRUCTION
A. DC Voltage Measuring
a. Connect the black test lead to the “COM ” jack and the red test lead to
the “V/Ω” jack.
b. Press to select U, to enter the DC voltage measurement.
c.Auto range by pressing the key, and manual range by press pressing the keys
d.Manual range： 0.000V  6.600V range
00.00V  66.00V range
000.0V  660.0V range
000.0mV  660.0mV range
WARNING!
Input voltage not to exceed 660V DC!
Use extreme caution when measuring high voltage.
