Configuration
Command Menu/MR-2300 Config/Features/
6.Signal-Silence Inhibit timer
[X] DISABLE->Default
[ ] 10 SEC
[ ] 20 SEC
[ ] 30 SEC
[ ] 1 MIN
Signal silence
inhibit
Use this function to inhibit the
SIGNAL SILENCE switch for
a desired length of time. This
time period should expire
before the signals may be
silenced.
Command Menu/MR-2300 Config/Features/
7. Aux. disconnect, disconnects
common alarm relay and common
supervisory relay
[ ] ENABLE
[X] DISABLE->Default
"Aux Disconnect"
disconnects alarm
relay
If enabled, the Common
Alarm Relay and the
Common Supervisory Relay,
in addition to the Auxiliary
Alarm Relay, are
disconnected when you
select “Aux Disconnect” (see
page 79). The MR-2300-PR
will not transmit a supervisory
or alarm event.
If disabled, selecting “Aux
Disconnect” (which acts like
an Aux. disconnect switch) will
have no effect on the
Common Alarm relay, the
Common Supervisory relay
and the MR-2300-PR.
Command Menu/MR-2300 Config/Features/
8.Auto Signal Silence Timer
[X] DISABLE->Default
[ ] 5 Min
[ ] 10 Min
[ ] 15 Min
[ ] 20 Min
[ ] 30 Min
Signal silence
Use this function to determine
the time period for which the
indicating circuits will sound
before they are automatically
silenced.
Command Menu/MR-2300 Config/Features/
9. Number of Remote Annunciators
or smart relays
[X] NONE->Default
[ ] 1
[ ] 2
[ ] 3
[ ] 4
[ ] 5
[ ] 6
Remote
Annunciators
Use this function to program
the number of remote
annunciators. Any
combination of remote
annunciators or smart relays
can be used as long as the
number does not exceed 6.
The annunciators’ addresses
should be: without gaps and in
sequence.
Command Menu/MR-2300 Config/Features/
10.Silence Alarm transmit
[X] DISABLE ->Def
[ ] ENABLE
Alarm transmit
affected by signal
silence
Use this function to allow the
alarm transmit and auxiliary
alarm relay to reset on
“SIGNAL SILENCE” rather
than the “RESET” switch.
Command Menu/MR-2300 Config/Features/
11.AC power fail delay timer
[X] NONE ->Default
[ ] 1 HRS
[ ] 2 HRS
[ ] 3 HRS
Use this function to delay the
AC power fail trouble for the
programmed time period. If
disabled, the AC power fail is
reported right away.
Table 9 Feature Config Menu (Continued)
Feature Default
Name in the
Configuration Utility
Description
Sig-Sil. Inhibit Tmr
[X] DISABLE
Aux Dis,Dis Alm&Spv
[X] DISABLE
Auto Sig-Sil. Timer
[X] DISABLE
No. of Remote Annun.
[X] NONE
Alm. Xmit-Sil.
[X] DISABLE
AC Pwr Fail Dly Tmr.
[X] NONE
