Configuration
Table 9 describes the options in the Feature Config menu.
Table 9 Feature Config Menu
Feature Default
Name in the
Configuration Utility
Description
Command Menu/MR-2300 Config/Features/
1. Manual Signal Silence
[X] ENABLE->Default
[ ] DISABLE
Manual signal
silence
Use this function to enable or
disable the SIGNAL SILENCE
operation from the front panel.
Command Menu/MR-2300 Config/Features/
2.Fire Drill
[X] ENABLE ->Default
[ ] DISABLE
Fire drill
Use this function to enable or
disable the FIRE DRILL
operation.
Command Menu/MR-2300 Config/Features/
3.Output Circuit Correlation
[X] DISABLE ->Def
[ ] ENABLE
Signal
correlations
If enabled, the programmed
correlations (see section
11.3.5 on page 61) are
effective. If disabled, the
programmed correlations are
ignored and all the output
circuits are correlated to all
the input circuits.
Command Menu/MR-2300 Config/Features/
4.Waterflow/Sprinkler Retard
Operation
[X] DISABLE ->Def
[ ] ENABLE
Retard waterflow
and sprinkler
circuit
If disabled, all the initiating
circuits configured as water
flow or sprinkler act as non-
verified alarms. If enabled,
retard operation is performed
for initiating circuits configured
as water flow or sprinkler.
(See Water flow Alarm and
Sprinkler Alarm description on
page 46.)
Command Menu/MR-2300 Config/Features/
5.Aux. disconnect, disconnects
Aux Alarm relay and all correlated
relays
[ ] ENABLE
[X] DISABLE->Default
"Aux Disconnect"
disconnects prog.
relay
If enabled, the Auxiliary
Alarm Relay and all
correlated relays are
disconnected when you
select “Aux Disconnect” (see
page 79). Correlated relays
include: RM312/RM306
relays and SRM-312 relays.
If disabled, only the Auxiliary
Alarm Relay is disconnected
when you select “Aux
Disconnect” (see page 79).
Manual Sig. Silence
[X] ENABLE
Opt. Ckt. Corr.
[X] DISABLE
Waterflow/Sprk. Retd
[X] DISABLE
To Next Page
