Secutron MR-2312-DDR User Manual

74
Configuration
Command Menu-->Dialer-Config
11.11.4Time Parameters
Figure 47 Time Parameters
Command Menu/Dialer-Config/Report Options
4.Aux Disconnect, Cancels Alarm &
Supv Reporting Thru dialer
[ ] ENABLE
[X] DISABLE ->Default
If this function is enabled,
the “Aux Disconnect” feature
(Command Menu, as a
switch) will block the alarm
and supervisory events from
being reported through the
built-in dialer.
Command Menu/Dialer-Config/Report Options
5.Dialer operation mode
[X] (U)DACT ->Default
[ ] DACT
Use this function to select
the functionality of the dialer.
In DACT mode only common
trouble/alarm/supervisory
are reported while in UDACT
mode all point information is
reported
Note: Refer to section 11.2.1 on page 55 for detailed instructions on making menu
selections.
Command Menu/Dialer-Config/Time Parameter
1.AC Loss delay
0 ->Default
0 to 20 hours
Use this function to delay the
reporting of AC loss trouble on the
dialer for the programmed time
period.
Command Menu/Dialer-Config/Time Parameter
2.Cellular report date
0 ->Default
Use this menu to set the test report
date for the cell phone setup. Set
this menu to 0 if there is no test
reporting for a cell phone, or if the
phone line is a regular line. Set this
menu from 01 to 28 to schedule a
test for Line 2 on a certain day of
the month. See section 11.11.5 for
more information.
When a cell phone service is
employed for the panel, it should
only be connected to telephone line
#2 CO interface. Also, the dial tone
detection feature of Line 2 should
be disabled for cell phone
application.
AuxDis Alm&Supv Rpt.
[X] DISABLE
Dialer Oper. Mode:
[X] (U)DACT
i
1 AC-Loss Delay
2 Cellphone Date
3 Auto-Test Time
-Time Parameter-
AC-Loss Delay(Hrs)
0
Cellular Report Date
0
