SEDEMAC GC1100 User Manual

GC1100 SEDEMAC
Page | 22
Level 0
Level 1 (On
screen)
Level 2 (On screen) *
Parameters (On screen)
Auto Exercise
Event 2
(AUTO
EXERCISE-2)
Auto Exercise
(EVENT 2)
Disable/Enable
Event Occurrence
(EVENT OCCURENCE)
Daily/Weekly/Monthly
Event Day
(EVENT DAY)
Runs Every day/Week
days/1 – 28
Start Time
(START TIME)
00:00 – 23:59 hour
Duration
(DG ON DURATION)
0-hour 1 min – 99 hour 59
mins
Load Transfer
(LOAD TRANSFER)
Disable/Enable
Cyclic Mode
(CYCLIC
CONFIG)
Cyclic Mode
(CYCLIC MODE)
Disable/Enable
Genset Off Time
(DG OFF DURATION)
1 – 720 min
Genset On Time
(DG ON DURATION)
1 – 720 min
Digital Inputs
(INPUTS)
Digital Input X
(DIG IN X)
X=A/B/C/D/E
Source
(SOURCE)
Refer Table 21
Polarity
(POLARITY)
Close to Activate/Open to
Activate
Action
(ACTION)
None/Notification/Warning
/Electrical Trip/Shutdown
Activation
(ACTIVATION)
Never/From Engine Start/
From Monitoring On/Always
Activation Delay
(ACTIVATION DELAY)
1 – 60 sec
Analog Inputs
Analog Input 1
(ENG
TEMP/DIG G)
Use Input As
(SENSOR SELECTION)
Not used/Digital Input G/
Anlg In Eng Temp
(Digital) Source
((DIG) SOURCE)
Refer Table 21
(Digital) Polarity
((DIG) POLARITY)
Close to Activate/Open to
Activate
(Digital) Action
((DIG) ACTION)
None/Notification/Warning
/Electrical Trip/Shutdown
(Digital) Activation
((DIG) ACTIVATION)
Never/From Engine Start/
From Monitoring On/Always
(Digital) Activation Delay
((DIG) ACTIVATION DELAY)
1 – 60 sec
(ETS) High Level Shutdown
(SHUTDOWN)
Disable/Enable
(ETS) High Level Shutdown
Threshold
(SHUTDOWN THRESHOLD)
27 – 300 C
