GC1100 SEDEMAC
Page | 23
Level 0
Level 1 (On
screen)
Level 2 (On screen) *
Parameters (On screen)
(ETS) High Level Warning
(WARNING)
Disable/Enable
(ETS) High Level Warning
Threshold
(WARNING THRESHOLD)
25 – 298 C
(ETS) Circuit Fault Action
(OPEN CKT ACTION)
None/Notification/Warning
/Electrical Trip/Shutdown
(ETS) Engine Temperature
Sensor Calibration Table
Refer Table 22
Analog Input 2
(Fuel LVL/DIG
H)
Use Input As
(SENSOR SELECTION)
Not used/Digital Input H/
Anlg In Fuel LVL
(Digital) Source
((DIG) SOURCE)
Refer Table 21
(Digital) Polarity
((DIG) POLARITY)
Close to Activate/Open to
Activate
(Digital) Action
((DIG) ACTION)
None/Notification/Warning
/Electrical Trip/Shutdown
(Digital) Activation
((DIG) ACTIVATION)
Never/From Engine Start/
From Monitoring On/Always
(Digital) Activation Delay
((DIG) ACTIVATION DELAY)
1 – 60 sec
(FLS) Low Fuel Level Shutdown
(SHUTDOWN)
Disable/Enable
(FLS) Low Fuel Level Shutdown
Threshold
(SHUTDOWN THRESHOLD)
0 – 78 %
(FLS) Low Fuel Level
Notification
(NOTIFICATION)
Disable/Enable
(FLS) Low Fuel Level
Notification Threshold
(NOTIFICATION THRESH)
2 – 80 %
(FLS) Fuel Tank Capacity
(FUEL TANK CAPACITY)
2 – 1000 litre
(FLS) Fuel Theft Warning
(FUEL THEFT ALARM)
Disable/Enable
(FLS) Fuel Theft Alarm
Threshold
(FUEL THEFT THRESHOLD)
1 – 100 % per hour
(FLS) Circuit Fault Action
(OPEN CKT ACTION)
None/Notification/ Warning
/Electrical Trip/ Shutdown
(FLS) Fuel Sensor Reference
(FUEL SENSOR REFERENCE)
Engine Body/Battery
Negative
(FLS) Fuel Level Sensor
Calibration Table
Refer Table 23
Analog Input 3
Use Input As
Not used/Digital Input F/
