9.18 ExP[1] – External Protection - Module
9.18.1
ExP[1]: Device Planning Parameters
ExP[1] . Mode [Device planning / Projected Elements]
use “-”, use
╚═▷ Device planning
P.1
External Protection - Module, general operation mode
ExP[1] . De󰈛nition [Device planning / De󰊟nition]
Trip Trip, Alarm
╚═▷ De󰊟nition
P.1
External Protection - Module: If set to “Alarm”: The function operates as a supervision function, i.e. a fault generates
neither alarm nor trip, but an »Alarm« signal gets issued instead. If set to “Trip”: The function operates as a
protection function, i.e. trips the breaker in case of a fault.
9.18.2
ExP[1]: Settings
ExP[1] . Function [Protection Para / ExP[1]]
Active Inactive, Active
╚═▷ Mode
P.1
Permanent activation or deactivation of module/stage.
ExP[1] . t [Protection Para / ExP[1]]
0.00s 0.00s . . . 60.00s P.1
Time delay for trip or alarm
ExP[1] . Trigger Signal [Protection Para / ExP[1]]
If: Device Variant/Inputs = Without Inputs
• “-”•
• “-”•
• “-”, Prot . DI 1, Prot . DI 2•
• “-”, Prot . DI 1, Prot . DI 2•
•
“-”, Prot . DI 1, Prot . DI 2
•
• “-”, Prot . DI 1, Prot . DI 2•
•
“-”
•
If: Device Variant/Inputs = Without Inputs
• “-”•
• “-”, Prot . DI 1, Prot . DI 2•
P.1
102 WIC1 WIC1-2.0-EN-REF
9 Protection Parameter
9.18 ExP[1] – External Protection - Module
