9.11 IG> – Ground (earth) current protection stage
9.11.1
IG>: Device Planning Parameters
IG> . Mode [Device planning / Projected Elements]
use “-”, use
╚═▷ Device planning
P.1
Earth current protection stage, general operation mode
IG> . De󰈛nition [Device planning / De󰊟nition]
Trip Trip, Alarm
╚═▷ De󰊟nition
P.1
Earth current protection stage: If set to “Alarm”: The function operates as a supervision function, i.e. a fault
generates neither alarm nor trip, but an »Alarm« signal gets issued instead. If set to “Trip”: The function operates as
a protection function, i.e. trips the breaker in case of a fault.
9.11.2
IG>: Settings
IG> . Function [Protection Para / IG>]
Active Inactive, Active
╚═▷ Mode
P.1
Permanent activation or deactivation of module/stage.
71WIC1WIC1-2.0-EN-REF
9 Protection Parameter
9.11 IG> – Ground (earth) current protection stage
