Seg WIC1 Reference Manual

9.12 IG>> – Ground (earth) current protection stage
9.12.1
IG>>: Device Planning Parameters
IG>> . Mode [Device planning / Projected Elements]
“-”
Only available if:
• Prot . Settings valid = Software•
“-”, use
╚═▷ Device planning
P.1
Earth current protection stage, general operation mode
IG>> . De󰈛nition [Device planning / De󰊟nition]
Trip
Only available if:
• Prot . Settings valid = Software•
Trip, Alarm
╚═▷ De󰊟nition
P.1
Earth current protection stage: If set to “Alarm”: The function operates as a supervision function, i.e. a fault
generates neither alarm nor trip, but an »Alarm« signal gets issued instead. If set to “Trip”: The function operates as
a protection function, i.e. trips the breaker in case of a fault.
9.12.2
IG>>: Settings
IG>> . Function [Protection Para / IG>>]
Active Inactive, Active
╚═▷ Mode
P.1
Permanent activation or deactivation of module/stage.
78 WIC1 WIC1-2.0-EN-REF
9 Protection Parameter
9.12 IG>> – Ground (earth) current protection stage
