ExP[2] . Condition [Protection Para / ExP[2]]

“-” “-”, I> . Pickup, I>> . Pickup, I>>> . Pickup, Ipeak> . Pickup, Prot .

Pickup

╚═▷

P.1

Assign a signal that must be active in additon to the external signal for making the »ExP« module start (pickup). (If

no signal has been assigned here then the »ExP« module always picks up as soon as the external signal becomes

active.)

ExP[2] . ExBlo [Protection Para / ExP[2]]

“-” “-”  . . .  Prot . Pos OFF

╚═▷

P.1

External blocking of the module if the state of the assigned signal is true.

9.19.3 ExP[2]: Input States

ExP[2] . ExBlo-I [Operation / Status Display / ExP[2]]

Module input state: External blocking

ExP[2] . Trigger Signal-I [Operation / Status Display / ExP[2]]

State of the module input: External trigger signal

ExP[2] . Condition-I [Operation / Status Display / ExP[2]]

State of the module input: Condition for External Protection

9.19.4

ExP[2]: Signals (Output States)

ExP[2] . Active [Operation / Status Display / All Actives]

[Operation / Status Display / ExP[2]]

Signal: active

ExP[2] . Trip [Operation / Status Display / Trips]

[Operation / Status Display / ExP[2]]

Only available if:

• ExP[2] . De󰊟nition = Trip•

Signal: Trip

107WIC1WIC1-2.0-EN-REF

9 Protection Parameter

9.19.3 ExP[2]: Input States

Seg WIC1 Reference Manual
