Enabling

Select the criterion for determining a manual CLOSE of the breaker. (After this,

the »SOTF« module gets enabled for a particular settable time.)

Selection list referenced by the following parameters:

• ╚═▷ SOTF . Enabling•

Enabling Description

Breaker Pos. A (manual) CLOSE command is determined based on the breaker position. (Note that

the determination of breaker positions needs to be con󰅰gured separately.)

Close Command A CLOSE command being executed enables the »SOTF« module.

Selection list referenced by the following parameters:

• ╚═▷ SOTF . Trigger•

• ╚═▷ ExP[2] . Condition•

Description

“-”

I> . Pickup Signal: Pickup

I>> . Pickup Signal: Pickup

I>>> . Pickup Signal: Pickup

Ipeak> . Pickup Signal: Pickup

Prot . Pickup Signal: General Pickup

Operating Mode

Operating Mode of the Cold Load Pickup stabilization

Selection list referenced by the following parameters:

• ╚═▷ CLPU . 50/51 Stab.•

• ╚═▷ CLPU . 50 N/G, 51 N/G Stab.•

Operating Mode Description

inactive The Cold Load Pickup stabilization is inactive.

Factor The Cold Load Pickup stabilization (temporarily) increases the pickup threshold of the

(phase and/or ground) overcurrent protection.

Block. The Cold Load Pickup stabilization (temporarily) blocks the (phase and/or ground)

overcurrent protection.

145WIC1WIC1-2.0-EN-REF

13 Selection Lists

Seg WIC1 Reference Manual
