CT . ECT pri [Field Para / CT]
60A
Only available if:
• Prot . Settings valid = Switches•
1A . . . 10000.0A P.1
This parameter denes the primary nominal current of the connected earth current transformer. If the earth current
is measured via the Holmgreen connection, the primary value of the phase current transformer must be entered
here.
4.1.3
CT: Values
CT . IL1 [Operation / Measured Values / Current ]
Measured value: Phase current (fundamental)
CT . IL2 [Operation / Measured Values / Current ]
Measured value: Phase current (fundamental)
CT . IL3 [Operation / Measured Values / Current ]
Measured value: Phase current (fundamental)
CT . IG meas [Operation / Measured Values / Current ]
Avail. depends on device type.
Measured value (measured): IG (fundamental)
CT . IG calc [Operation / Measured Values / Current ]
Measured value (calculated): IG (fundamental)
Since the value might be unreliable or invalid for low phase currents it is displayed as “-0.0” in this case.
CT . phi IL1 [Operation / Measured Values / Current ]
Measured value (calculated): Angle of Phasor IL1
Since the angle might be unreliable or invalid for a too low amplitude it is displayed as 360°” in this case.
CT . phi IL2 [Operation / Measured Values / Current ]
Measured value (calculated): Angle of Phasor IL2
Since the angle might be unreliable or invalid for a too low amplitude it is displayed as 360°” in this case.
CT . phi IL3 [Operation / Measured Values / Current ]
Measured value (calculated): Angle of Phasor IL3
Since the angle might be unreliable or invalid for a too low amplitude it is displayed as 360°” in this case.
23WIC1WIC1-2.0-EN-REF
4 Field settings
4.1.3 CT: Values
