CT . phi IG meas [Operation / Measured Values / Current ]
Avail. depends on device type.
Measured value (calculated): Angle of Phasor IG meas
Since the angle might be unreliable or invalid for a too low amplitude it is displayed as 360°” in this case.
CT . phi IG calc [Operation / Measured Values / Current ]
Measured value (calculated): Angle of Phasor IG calc
Since the angle might be unreliable or invalid for a too low amplitude it is displayed as 360°” in this case.
CT . IL1 H2 [Operation / Measured Values / Current ]
Measured value: 2nd harmonic/1st harmonic of IL1
CT . IL2 H2 [Operation / Measured Values / Current ]
Measured value: 2nd harmonic/1st harmonic of IL2
CT . IL3 H2 [Operation / Measured Values / Current ]
Measured value: 2nd harmonic/1st harmonic of IL3
CT . I0 [Operation / Measured Values / Current ]
Measured value (calculated): Zero current (fundamental)
CT . I1 [Operation / Measured Values / Current ]
Measured value (calculated): Positive phase sequence current (fundamental)
CT . I2 [Operation / Measured Values / Current ]
Measured value (calculated): Unbalanced load current (fundamental)
CT . %(I2/I1) [Operation / Measured Values / Current ]
Measured value (calculated): I2/I1, phase sequence will be taken into account automatically.
CT . IL1 RMS [Operation / Measured Values / Current RMS]
Measured value: Phase current (RMS)
CT . IL2 RMS [Operation / Measured Values / Current RMS]
Measured value: Phase current (RMS)
CT . IL3 RMS [Operation / Measured Values / Current RMS]
Measured value: Phase current (RMS)
24 WIC1 WIC1-2.0-EN-REF
4 Field settings
4.1.3 CT: Values
