Prot . Rst. Fault No. [Operation / Reset]
False False, True
╚═▷ True or not true
P.1
Direct Command to Reset the Fault number
Prot . Force Trip Cmd [Service / Prot]
Inactive Inactive, Active
╚═▷ Mode
P.1
Direct Command to force the device to issue a trip command (for testing purposes). This has the following additional
e󰅯ects:
- The signals »Prot . Pickup«, »Prot . Trip« and »Prot . TripCmd« are set.
- A fault record is created.
- The breaker failure protection is triggered.
- An automatic reset is executed.
Prot . Force FI Pulse [Service / Prot]
Inactive Inactive, Active
╚═▷ Mode
P.1
Direct Command to force an impulse at the FI output of the WIC1 (for testing purposes).
9.4
Prot: Input States
Prot . ExBlo TripCmd-I [Operation / Status Display / Prot]
Module input state: External Blocking of the Trip Command
9.5
Prot: Signals (Output States)
Prot . Active [Operation / Status Display / All Actives]
[Operation / Status Display / Prot]
Signal: active
Prot . Trip [Operation / Status Display / Trips]
[Operation / Status Display / Prot]
Signal: General Trip
44 WIC1 WIC1-2.0-EN-REF
9 Protection Parameter
9.4 Prot: Input States
