SOTF . Trigger [Protection Para / SOTF]

Ipeak> . Pickup “-”, I> . Pickup, I>> . Pickup, I>>> . Pickup, Ipeak> . Pickup, Prot .

Pickup

╚═▷

P.1

Assign the type of pickup signal that triggers the SOTF module. If the assigned pickup signal is issued, the SOTF

module itself picks up.

SOTF . ExBlo [Protection Para / SOTF]

“-” “-”  . . .  Prot . Pos OFF

╚═▷

P.1

External blocking of the module if the state of the assigned signal is true.

9.17.3

SOTF: Input States

SOTF . ExBlo-I [Operation / Status Display / SOTF]

Module input state: External blocking

SOTF . Trigger-I [Operation / Status Display / SOTF]

State of the module input: Assign the type of pickup signal that triggers the SOTF module. If the assigned pickup

signal is issued, the SOTF module itself picks up.

9.17.4

SOTF: Signals (Output States)

SOTF . Active [Operation / Status Display / All Actives]

[Operation / Status Display / SOTF]

Signal: active

SOTF . Trip [Operation / Status Display / Trips]

[Operation / Status Display / SOTF]

Only available if:

• SOTF . De󰊟nition = Trip•

Signal: Trip

SOTF . Alarm [Operation / Status Display / Alarms]

[Operation / Status Display / SOTF]

Only available if:

• SOTF . De󰊟nition = Alarm•

Signal: Alarm

100 WIC1 WIC1-2.0-EN-REF

9 Protection Parameter

9.17.3 SOTF: Input States
