Seg WIC1 Reference Manual

I> . I [Protection Para / I>]
1.00In If: I> . Char = DEFT
• 0.35In . . . 20.00In•
If: I> . Char = IEC NINV
• 0.35In . . . 2.50In•
If: I> . Char = IEC VINV
•
0.35In . . . 2.50In
•
If: I> . Char = IEC EINV
•
0.35In . . . 2.50In
•
If: I> . Char = IEC LINV
• 0.35In . . . 2.50In•
If: I> . Char = RINV
•
0.35In . . . 2.50In
•
If: I> . Char = HV Fuse
• 0.35In . . . 2.50In•
If: I> . Char = FR Fuse
•
0.35In . . . 2.50In
•
If: I> . Char = IEEE MINV
•
0.35In . . . 2.50In
•
If: I> . Char = IEEE VINV
•
0.35In . . . 2.50In
•
If: I> . Char = IEEE EINV
•
0.35In . . . 2.50In
•
If: I> . Char = EF Curve
•
0.35In . . . 2.50In
•
P.1
If the pickup value is exceeded, the protection stage starts to time out to trip.
WARNING: Check the Technical Data and ensure that the actual overcurrent settings for this pickup threshold and the
trip delay comply with the technical limits of the phase current inputs! (The device allows for overcurrent settings
that are out of the permitted range of current values.)
I> . Char [Protection Para / I>]
DEFT DEFT . . . EF Curve
╚═▷ Char
P.1
Characteristic
51WIC1WIC1-2.0-EN-REF
9 Protection Parameter
9.8.2 I>: Settings
