Seg WIC1 Reference Manual

I>> . Alarm [Operation / Status Display / Alarms]
[Operation / Status Display / I>>]
Only available if:
• I>> . De󰊟nition = Alarm•
Signal: Alarm
I>> . Pickup [Operation / Status Display / Pickups]
[Operation / Status Display / I>>]
Signal: Pickup
I>> . Trip IL1 [Operation / Status Display / I>>]
Only available if:
• I>> . De󰊟nition = Trip•
Signal: Trip due to a fault in phase L1
I>> . Trip IL2 [Operation / Status Display / I>>]
Only available if:
• I>> . De󰊟nition = Trip•
Signal: Trip due to a fault in phase L2
I>> . Trip IL3 [Operation / Status Display / I>>]
Only available if:
• I>> . De󰊟nition = Trip•
Signal: Trip due to a fault in phase L3
I>> . Alarm IL1 [Operation / Status Display / I>>]
Only available if:
• I>> . De󰊟nition = Alarm•
Signal: Alarm due to a fault in phase L1
I>> . Alarm IL2 [Operation / Status Display / I>>]
Only available if:
• I>> . De󰊟nition = Alarm•
Signal: Alarm due to a fault in phase L2
62 WIC1 WIC1-2.0-EN-REF
9 Protection Parameter
9.9.4 I>>: Signals (Output States)
