Seg WIC1 Reference Manual

I2> . t [Protection Para / I2>]
0.1s
Only available if:
• I2> . Char = DEFT•
0.00s . . . 300.00s P.1
Time delay for trip or alarm
I2> . tChar [Protection Para / I2>]
0.1
Only available if:
• I2> . Char = IEC NINV•
• I2> . Char = IEC VINV•
• I2> . Char = IEC EINV•
• I2> . Char = IEC LINV•
•
I2> . Char = RINV
•
•
I2> . Char = HV Fuse
•
• I2> . Char = FR Fuse•
• I2> . Char = IEEE MINV•
•
I2> . Char = IEEE VINV
•
• I2> . Char = IEEE EINV•
•
I2> . Char = EF Curve
•
0.05 . . . 10.00 P.1
Time multiplier/tripping characteristic factor. The setting range depends on the selected tripping curve.
I2> . tMin [Protection Para / I2>]
0.00s
Only available if:
• I2> . Char = IEC NINV•
• I2> . Char = IEC VINV•
• I2> . Char = IEC EINV•
• I2> . Char = IEC LINV•
•
I2> . Char = RINV
•
•
I2> . Char = HV Fuse
•
• I2> . Char = FR Fuse•
• I2> . Char = IEEE MINV•
•
I2> . Char = IEEE VINV
•
• I2> . Char = IEEE EINV•
•
I2> . Char = EF Curve
•
0.00s . . . 20.00s P.1
Minimum trip delay time. Independent of the measured current values, the trip delay time does never fall below the
minimum that is set here.
89WIC1WIC1-2.0-EN-REF
9 Protection Parameter
9.14.2 I2>: Settings
