Sega GHOST SQUAD - EVOLUTION - 4 Part Descriptions

10
PART DESCRIPTIONS
4
(Width x Depth x Height) (Weight)
Gun Cabinet 1,140 mm × 1,090 mm × 1,010 mm 98 kg
PTV Cabinet 1,140 mm × 555 mm × 1,670 mm 100 kg
PTV Base 1,200 mm × 620 mm × 310 mm 26 kg
Billboard 1,170 mm..x...410 mm x 385 mm 18 kg
WhenAssembled
1,200 mm x 1,680 mm x 2,230 mm 253 kg
FIG. 4 Name of Each Part
TABLE 4 Major Measurements of Each Unit Upon Purchase
PART DESCRIPTIONS 4
