EXPLANATION OF TEST AND DATA DISPLAY
9
9-3b OUTPUT TEST
The condition of each output device can be checked. Periodically check the condition of each output device on this
screen. Conditions are normal if each device operates and yields output as indicated below.
<Operation>
1
Press the SERVICE Button and move the cursor to the item (output device) you want to test.
2
Whenever the TEST Button is pressed, the display on the right side of the item goes from OFF to ON and
the selected output device operates. Confirm that the device operates normally.
3
Press the SERVICE Button and move the cursor to EXIT.
4
When the TEST Button is pressed, the game test mode menu screen reappears.
<Menu Explanation>
PLAYER 1 START LAMP: When ON the player 1 lamp will illuminate.
PLAYER 2 START LAMP: When ON the player 2 lamp will illuminate.
PLAYER 1 LAMP HOLDER: When ON the player 1 lamp holder will illuminate.
PLAYER 2 LAMP HOLDER: When ON the player 2 lamp holder will illuminate.
PLAYER 1 GUN REATION: When ON the player 1 gun will rattle.
PLAYER 2 GUN REATION: When ON the player 2 gun will rattle.
EXIT: Game Test Menu screen reappears.
FIG. 9-3b OUTPUT TEST Screen
OUTPUT TEST
PLAYER 1 START LAMP OFF
PLAYER 2 START LAMP OFF
PLAYER 1 HOLDER LAMP OFF
PLAYER 2 HOLDER LAMP OFF
PLAYER 1 GUN REACTION OFF
PLAYER 2 GUN REACTION OFF
-> EXIT
SELECT WITH SERVICE BUTTON
AND PRESS TEST BUTTON
