16-2 COMPOSITION OF THE GAME BOARD
ASSY CASE LBG L 1GB LGJ EXP (844-0012D-02)
FIG. 16-2a
FIG. 16-2b
Use this product with the DIP SW settings shown in the figure below.
DIP SW SETTING
● With the key chip inserted into it, this board serves as a special-purpose game
board for the product.
● Use with the dip switches (DIP SW) on the board at the prescribed settings. If
settings do not match the product, an error message will be displayed. In some
cases, the game cannot be started.
BOARD NUMBER STICKER
DIP SW
KEY CHIP
To Next Page
