REPLACING THE FLUORESCENT LAMPS
85
13
1
Turn off the power.
2
Use a stool or steps when working on the top of the cabinet. Remove the two screws from the top of the
billboard box.
Replacing the Billboard Box Florescent Lamp
FIG. 13a
3
Remove the FL cover plate to reveal FL lamp..
FIG. 13b
4
Change the florescent lamp.
5
Re-build the billboard by following steps 1 to 4 in reverse order..
SCREW (2)
M4x12, w/flat & spring washers
FL COVER PLATE
FLORESCENT LAMP 30W
LT1014
