Manual [en] 4
Technical Data
Properties Values
Network connector
Logical:
Physical:
IEEE 802.3 (1000BaseT, 100BaseTX and 10BaseT)
1 × RJ-45 (STP, Category 5 or better)
Device connection • 4 × USB 3.0 SuperSpeed (USB Ports 1–4)
• 4 × USB 2.0 Hi-Speed (USB Ports 5–8)
Current Input • 240 mA at 12 VDC without load
• max. 700 mA at 12 VDC with full load on the USB
ports
Power consumption • approx. 3.1 W when idle
• typ. approx. 7.5 W when operating 8 TSE mo-
dules on the USB ports
• typ. approx. 66 kWh/year
Operating environment Ambient temperature: 5–40 °C
Relative humidity: 20–80 %
Dimensions Width: 215 mm
Height: 45 mm
Depth: 155 mm
Weight: 1070 g (with housing cover)
Network connector (RJ-45)
(on the back)
Connector for the included
power pack
(on the back)
Activity LED
(yellow)
Status LED
(green)
Restart Reset
Link LED
(green)
Power LED
(green)
USB Ports 1–8
with USB Port LED
8
1
