Seiko Precision BP-6000 - Print Head Adjustment

8
1. Introduction
❏ Physical dimension(Model A)
Weight: 44.1 lbs. (20 kg)
17.5"
(445mm)
19.9"
(505mm)
24.4" (620mm)
15.4"
(390mm)
17.1"
(435mm)
10.2"
(260mm)
12.0 "
(305mm)
Sound Seal Cover
11.6"
(295mm)
∗Paper Rack in flat position
(Continuous paper setting)
∗Paper Rack in upright position
(Single sheet setting)
∗Paper Rack in flat position
(Continuous paper setting)
