1-6
Frequency
Range Resolution Accuracy Overload protection
100 Hz 0.01 Hz
1 kHz 0.0001 kHz
10 kHz 0.001kHz
100 kHz 0.01kHz
1 MHz 0.0001MHz
10 MHz (2405) 0.001MHz
±(0.05%+5)
600V DC
or AC rms
The guaranteed range is below 5 MHz.
RPM (S2401, S2405, S2505)
Range Resolution Accuracy
240 - 60,000 1 RPM ±(0.05%+5)
Pulse Width (S2401, S2405, S2505)
Range
2uS-500mS (Pulse Width > 2uS)
% Duty (S2401, S2405, S2505)
Range
25% - 75%
Only S2800
Function Range Resolution Accuracy
RPM 120 - 12,000 1RPM ± 2RPM
% Duty 1% - 98%
Dwell 3.6° - 352.8°
Pulse Width 2 uS - 450 mS (Pulse Width > 2 uS)
Frequency 2Hz - 1MHz
