2.6. Assembly Procedures
Generally, assembly procedures follow a reverse sequence of
disassembly procedures. As some differences do apply, assembly is
described separately in the following paragraphs. Begin assembly at
the appropriate level, as defined by the heading. References are
made to items in below Figure for assembly details of standard meter
parts.
2.6.1. Layout for LCD Assembly
PCB
EL
LCD
PC Cover
① LCD Cover:
② LCD:
③ EL:
④ SUB PCB
We recommend that do not remove LCD from SUB PCB.
