3-1
3. Performance Testing
3.1. Introduction
This chapter of the Service Manual provides performance tests that
can be used at any time to verify the meter operation within published
specifications. A complete calibration procedure is also included. The
performance test and, if necessary, the calibration procedure can be
performed periodically and after service or repair.
3.2. Required Test Equipment
The following equipment, or a suitable equivalent, is required for
performance testing and calibration:
Description Minimum requirements Examples
Multifunction Calibrator Refer to 4808 specification 4808
Multifunction Calibrator Refer to 9100 specification 9100
Arbitrary function generator
Refer to HC9302
specification
HC930
Function generator Refer to G5100 specification G5100
Power supply Refer to P6100 specification P6100
Resistance calibrator
Tool for a short circuit test
To test current and voltage
Personal Computer IBM computer
3.3. Performance Tests
The following performance tests are provided to ensure that the meter
is in proper operating condition.
3.3.1. Scope center Tests
1. Turn off the equipment and turn on the equipment.
2. Move to DCV (Press FUNC, F1 and then select DCV; then press
F3, F4, F4).
3. Press DIV button; then press the F1, Æ, F2, Æ, F3 and Æ button
to change of A/Div,. B/Div and H/Div to AUTO mode.
