Seli STS-03 - Page 56

15 Parameterisation
56
Para-
meter
Denomination
Value range
Description
dsp
Display switchover
turB, te mp, ALT
Definition of which
measured value is to be
displayed:
turB: opacity/absorption
te mp: temperature
Alt: opacity/absorption
and temperature
alternating
Regardless of the display
switchover, the analogue
output always delivers a
signal depending on the
opacity.
MRB
Start of measuring range
(Measuring begin)
0 … 19999
Defines the 4mA point.
MRE
End of measuring range
(Measuring end)
0 … 19999
Defines the 20mA point.
dAM
Damping
(Damping)
0.0 … 200.0
Damps the measured
value for opacity.
r-0-
Zero point range
(Range of Zero)
0 … 1/3 Mbr.
Defines a range in display
digits around the zero
point where the measured
value is set to 0.
Don
Switching-on point
(Digital Output on)
0 … 19999
Defines the switching-on
point.
doff
Switching-off point
(Digital Output off)
0 … 19999
Defines the switching-off
point.
dt yp
Switching function
(Digital Output type)
no, nC
no = normally open
nC = normally closed
ddly
Switching delay
(Digital Output delay)
0.0 … 200.0s
Delays the switching point
by up to 200s.
Aoll
Lower output limit
(Analogue Output lower
limit)
3,5 … 22.5mA
Defines the minimum
output current.
Aoul
Upper output limit
(Analogue Output upper
limit)
3,5 … 22.5mA
Defines the maximum
output current.
Mout
Leakage current
(Malfunction Output)
3,5 … 22.5mA
If the transmitter detects
an internal error, an error
code is shown on the
display and the defined
current signal is output.
Aulo
Keylock
0 … 100min.
Upon corresponding
operating time, the
keyboard is locked in
order to prevent
unauthorised operation.
The setting 0 will
deactivate the keylock.
rst
Reset
no, Yes
Resetting the user
parameters to the default
settings; the calibration
values are maintained
esc
Start/end of menu
not applicable
Menu input and output
(saving the entered
parameters)
