15 Parameterisation
15.1 User menu
Incorrect settings in the parameters may result in the output of
incorrect measured values and switching points. This may result in
accidental process influence.
Please make sure that only authorised and trained personnel
perform changes to the parameterisation.
The sensor is parameterised using the function keys on
the display.
The user menu can be opened by pressing the Enter button. The
individual parameters can be accessed by pressing the arrow
buttons.
If you want to configure a parameter, you must press the Enter
button again, use the arrow button to select the desired setting,
and confirm your selection finally using the Enter button.
At the end of the parameters you can return to the display by
pressing ESC (Escape) and the Enter button.
User menu
The bold and underlined values are the standard user
parameters. The “RST” function resets all user parameters to the
factory settings.
Para-
meter
Denomination
Value range
Description
ESc
Start/end of menu
not applicable
Menu input and output
MP r
Measuring principle
tur opacity
AbS absorption
unIt
Selection of the
measuring unit
MPR = AbS
MPR = tur
AU (Au)
cdu (CDU)
Ebc (EBC)
FAu (FAU)
tEF (TEF)
MGL (mg/l)
cdu (CDU)
cdud
Decimal place of the
user unit
0….0.000
Defines the decimal places
of the user unit (cdu)
cdu
User unit
0….19999
Defines the value range of
the user unit (cdu)
ATTENTION!

