19 Technical data
19.1 Standards
EN 61326-1: 10-2006
EN 61326-2-3: 5-2007
DIN/EN 27027 (ISO 7027)
19.2 Specification
Sensor specifications
Measuring range
0…6 OD /0..3 AU /0...3250 EBC/0…13,000 FAU
Wavelength
880 nm
Light source
LED
Optical path length
5mm
Material
Stainless steel 1.4435 (316L)
Surface quality
Electropolished < Ra 0.37µm
Measuring window
Sapphire
Supply voltage
24VDC
Output current
4…20mA
Switching output
NO or NC parameterisable 150mA max
Degree of protection
IP67/IP69K
Cable connection
M12 connector 5-pin
Cable length
3m or 5m
Process connection
G ½“ for process connections
(modular@process)
