SEM 2SSD - Page 26

26
508.366.1488 | www.semshred.com
1. Remove front and rear deflectors. Requires 1/2” wrench.
o
2. Remove bolts from rotor knives and remove knives.
o CAUTION – Knives are sharp.
o Requires 5/16” Allen drive socket bit.
3. Remove bolts from bed knives.
o Replace one knife at a time.
o Make sure to keep track of the bed knife clamps.
4. Wipe bed knife clean and place atop bed knife seat with blades facing rotor. Front knife will be upside down,
“logo side down”.
Front Deflector
Rear Deflector
Figure 3
Figure 4
Figure 5 – Shown with Bolts
Bolts to Remove
(Both Sides)
