5. Install bed knife bolts with six 3/8”- 16 x 1 1/2" socket head cap screw and six 3/8” thick black washer through
top of clamp – set to hand tight. Flat side of washer should be touching clamp.
6. Repeat steps 4-6 for the second bed knife.
7. Wipe off rotor flats and rotor knives before attaching them one at a time with – 9 – 3/8-24 x 3/4" socket head
cap screw.
o Beveled edge of knife sits in notch of rotor corner.
Figure 6 – Bed Knives as seen from
Drive Plate
