Sena ECONO - Installing Shield Visor; Removing Cheek Pad

11
ABOUT THE ECONO BLUETOOTH HELMET
1.4.4 Installing Shield Visor
Hook C
1
2
Hook A Hook B
1. Open a shield visor to fully opened position, and
insert hook C.
2. Pull the trigger down and insert hook A and hook B.
3. Repeat the process on the other side.
1.4.5 Removing Cheek Pad
1. Remove the three snaps of the cheek pad from the
helmet.
2. Remove a lower portion of a cheek pad from a
bracket.
3. Pull the rear of the cheek pad off the helmet.
