SMD 989– User Manual
Page 99 (105)
SMD 963 Multistream DVB-S2 Option
In Addition to SMD 910 Specifications
ASI Serial TS Input –
Connector: (4 Total) BNC, female
Impedance: 75 ohms
Standard: ETSI EN 50083-9 DVB ASI
Data Bit Rate: 270 Mbps
Packet Size: 188 or 204 byte support
Transmission Mode: Burst and packet mode support
Min TS Rate Supported: 0.5 Mbps
Max TS Rate Supported: 160 Mbps
IP Serial TS Input –
Connector: (1) – 10/100/1000 Auto-negotiating Base-T
RJ-45 Ethernet Port
Input format: UDP, RTP, and RTP with extension headers
Multicast and Unicast
Number of Streams: Up to 6 streams for multistream
Bitrate Range: 0.5 – 160 Mbps
Packets/IP Frame 1-7 MPEG Packets/IP Frame
IGMP Compatibility: Version 2 and 3
Min TS Rate Supported: 0.5 Mbps
Max TS Rate Supported: 160 Mbps
Network Jitter Buffer: 100 KB to 4MB
Multistream –
Modes: DVB-S2 Single Stream CCM
DVB-S2 Multistream CCM
DVB-S2 Multistream VCM
TS Supported: Up to 6 any combination of ASI and IP
SMD 964 DVB-S2/DVB-S2X Modulation
Supported modulation schemes and FEC (SMD 910 or SMD 912(A))
DVB-S2
QPSK Includes all formats of SMD 962
8PSK Includes all formats of SMD 962
16APSK 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
32APSK 3/4, 4/5, 5/6, 8/9, 9/10
*9/10 is not supported in Short Frame Mode
DVB-S2X
QPSK Includes all formats of SMD 962
8PSK Includes all formats of SDM 962
16APSK 2/3, 3/4 , 4/5, 5/6, 8/9, 9/10, 26/45,3/5,
32APSK 3/4 , 4/5, 5/6, 8/9, 32/45, (2/3 Short FECFRAME)
32APSK 9/10, 11/15, 7/9, (Normal FECFRAME only)
32 APSK-L 32/45 Normal FECFRAME only
64 APSK 11/15, 7/9, 4/5, 5/6, (Normal FECFRAME only)
64APSK-L 32/45 (Normal FECFRAME only)
Min Symbol Rate: 0.5 MSps
Max Symbol Rate: Up to 45 MSps with SMD 966 License
Frame length: Short (16,200 bits) or Normal (64,800 bits)
Roll-off Factor: 20%, 25%, 35%
